Model NO.
SELS-2835X192-12/24 –5YD/E
Quantity:
Product Parameter
Model NumberSELS-2835X192-12/24 –5YD/E
Beam Angle120°
Waterproof GradeIP20/IP65
Color Temperature(CCT)2700K / 3000K / 4000K / 6500K
Lamp Power14W/mt,21W/mt
Luminous Efficacy(lm/w)Max: 165
Lamp Luminous Flux(lm)Max: 3360lm/w
FPC Width10mm
Warranty(Year)5-YEAR
CRI (Ra>)80/90
Life time(Hour)50,000
Switch ModeBluetooth Remote Control
Wifi Manual Button
Source2835 SMD
Support Dimmeryes
Cutting Unit20.8mm,41.7mm
Input Voltage(V)DC 12 / 24V
Length5mt, any length can
be customized
Ambient Temp. ()(-20~+50)
Storage Temp. ()(-20~+60)
Lamp Body MaterialCopper
CertificationCE EMC FCC PSE RoHS
Lighting solutions serviceLighting and circuitry design;
DIALux evo layout; CAD layout



5Years Warranty Series
Part No.SELS-2835X192-12/24 –5YDSELS-2835X192-12/24 –5YE
VoltageDC 12/24VDC 12/24V
LED Qty/mt192pcs192pcs
Watt/mt14W/21W14W/21W
FPCB Width10mm10mm
Cutting Unit20.8mm/41.7mm20.8mm/41.7mm
Efficiency150-165lm/W150-165lm/W
Lumen/mt2170-2310LM3150-3360LM
CRI (Ra>)>80>80
Product Description
192LEDs 165LM/W 2835 High Lumen LED Strip Light 5Years Warranty can do IP20/IP65, Different waterproof grade. Color can be Warm White, Natural White, Pure White, etc.
1.192pcs 2835 SMD per meter, Cut every 4pcs LEDs for 12VDC, Cut every 8pcs LEDs for 24VDC, to reach high lumen efficacy;
2.Standard packing is 5m per roll; Any other different length can be customized;
3.Waterproof grade IP20/IP65 option;
4.5 years warranty.
5. Low power consumption
6. Flexible ribbon for curving around bends
7. Long life span 50,000+ hours
8. Completely smooth and even light spread, solving the uneven luminous problem
9. Ultra-bright but running at low temperature
Application

192LEDs 165LM/W 2835 High Lumen LED Strip Light 5Years Warranty

1. It’s widely used as a decorative lights, and use it as the lights
2. LED Luminous characters;
3. Backlight of signage, Channel letters lighting;
4. Festival, exhibition,Stage decoration, weedings;
5. Landscape layout lighting; Hotels, night clubs, shopping malls, offices.



Product packaging

Installation Instructions
