| Product Parameter | |
| Model Number | SELS-2835X60-24-YCC |
| Beam Angle | 120° |
| Waterproof Grade | IP20/IP65/IP67/IP68 |
| Color Temperature(CCT) | 2700K / 3000K / 4000K / 6500K |
| Lamp Power | 5W/mt |
| Luminous Efficacy(lm/w) | 110 |
| Lamp Luminous Flux(lm) | 550lm/w |
| FPC Width | 10mm |
| Warranty(Year) | 3-YEAR |
| CRI (Ra>) | 80 |
| Life time(Hour) | 50,000 |
| Switch Mode | Bluetooth Remote Control Wifi Manual Button |
| Source | 2835 SMD |
| Support Dimmer | yes |
| Cutting Unit | 50mm |
| Input Voltage(V) | DC 24V |
| Length | 50mt, any length can be customized |
| Ambient Temp. (℃) | (-20~+50℃) |
| Storage Temp. (℃) | (-20~+60℃) |
| Lamp Body Material | Copper |
| Certification | CE EMC FCC PSE RoHS |
| Lighting solutions service | Lighting and circuitry design; DIALux evo layout; CAD layout |
| 2835 Constant Current Series | |||
| Part No. | SELS-2835X60-24-YCC | SELS-2835X120-24-YCC | SELS-2835X240-24-YCC |
| Voltage | DC 24V | DC 24V | DC 24V |
| LED Qty/mt | 60pcs | 120pcs | 240pcs |
| Watt/mt | 5W | 10W | 20W |
| FPCB Width | 10mm | 10mm | 12mm |
| Cutting Unit | 100mm | 50mm | 25mm |
| Efficiency | 110lm/W | 115lm/W | 120lm/W |
| Lumen/mt | 550LM | 1150LM | 2400LM |
| Product Description | |
| Constant Current LED Strip Lights Ultra long 24V 50mt 60LEDs can do IP20/IP65/IP67/IP68, Different waterproof grade. Color can be Warm White, Natural White, Pure White, etc. 1. 60led 2835smd/m without resistors; IC Build‐In LED with constant current, ensure each led working in same current to assure longer lifetime; 2. 3 years warranty; 3. Normal working voltage is 24V DC, wide voltage range can reach from 16V to 40V; 4. Different waterproof grade can meet requirements in different use condition; 5. Standard packing is 50m per roll; Any other different length can be customized; 6. Every 6leds as a unit can be cut. | |
| Application | |
Constant Current LED Strip Lights Ultra long 24V 50mt 60LEDs with widely application below: 1. This Constant Current LED Strip Lights Ultra long it suitable for outdoor accent lighting, save a lot of power suppliers |
| Product packaging |
| Installation Instructions |
Notice：
1. Installation Constant Current LED Strip Lights Ultra long must comply with local international electrical safety instructions.
2. In order to ensure Constant Current LED Strip Lights Ultra long safe and correct installation, the installing person must be a qualified electrician with a license.
3. The installation of Constant Current LED Strip Lights Ultra long should comply with CE standard; With constant voltage LED power supply.
4. Do not install the Constant Current LED Strip Lights Ultra long in overheat environment.
5. Do not install the non-waterproof Constant Current LED Strip Lights Ultra long in outdoor or damp environment.
6. Make sure the cables use for connect the power supply, Constant Current LED Strip Lights Ultra long and any dimmer are of standard size. Please calculate the voltage drop and the maximum rated current when selecting the cables. It will cause the cable overheat and burned if select improper cables and installation.
7. The Constant Current LED Strip Lights Ultra long with 3 or 5 years warranty，it's according to the ship out date.
8.If there is any technical or sales questions, please feel free to contact us at sales@se.lighting.
FAQs:
Constant Current Flexible LED Strips come with many pros and a few cons. Whether you’re looking for LED Light Strips for bedrooms, LED Light Strips for kitchen cabinets, or bedroom LED light strips etc… the answers to these common questions may help.
Q: Are Constant Current LED Strip Lights safe?
LED Strip Lights are safe as long as they’re installed and operated according to the manufacturer’s instructions. For example, indoor lights shouldn’t be installed outside, and some lights should not be installed where they can get wet.
Q: How long can you run Constant Current LED Strip Lights?
Constant Current Flexible LED Strips can run for hours on end without being shut off. They get warm, but they’re designed to underdrive the LEDs, which means they don’t overheat.
Q: Do Constant Current LED Strip Lights have to be plugged in to work?
Yes, you have to leave Constant Current Flexible LED Strips plugged in for them to work.
Q: Do Constant Current LED Strip Lights work with dimmer switches?
Almost every LED Light Strip is compatible with a dimmer switch. In order to make an Constant Current Flexible LED Strips dimmable, it’s input wire must first be connected to a dimmer unit, then connect the unit to the power supply.
Q: How can I create ambient light with Constant Current LED Strip Lights?
To create ambient light in your home with Constant Current Flexible LED Strips, the optimal locations are under or above cabinets and counters in the kitchen, behind mirrors in the bathroom, or even around large pieces of furniture like bookshelves and home entertainment units.
Q: How do you properly recycle old Constant Current LED Strip Lights?
Constant Current Flexible LED Strips can be disposed of by recycling them by taking them to a local recycling center.
Q: How long do Constant Current LED Strip Lights last?
Most Constant Current Flexible LED Strips are built to last for up to 50,000 hours of use, which is roughly 10 to 20 years of runtime.
