Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights
Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights
Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights
Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights
Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights
Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights
Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights
Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights
Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights
Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights
Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights
Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights
Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights
Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights
Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights
Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights
Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights
Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights
Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights

Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights

Model NO.
SES-W200 L type
Quantity:
Product Parameter
Model NumberSES-W200
Beam AngleTypeⅡ 70*150°  TypeⅢ 80*150°
Waterproof GradeIP66
Color Temperature
(CCT)
3000K/4000K/5000K/6000K
Power50W/75W/100W/150W/200W/300W
Pole Size60mm Option
CertificationCE ROHs SAA ETL DLC
ApplicationHighway lighting and other outdoor places.
Warranty(Year)5-YEAR
Luminous Efficacy(lm/w)130&150
Life time(Hour)50,000
Power Factor (PF)≥0.95
IK RateIK10
Flicker Freeyes
DimmableNormal / 0-10V Dimmable /
DALI Dimmable
Input Voltage(V)AC 220-240V/100-277V
Surge Protection10KV, Philips SP1 type
LED3030 SMD
Ambient Temp. ()-30~+50℃
Storage Temp. ()-40~+80℃
Key MaterialAluminum Alloy + PMMA
DriverTUV/Meanwell
CRI (Ra>)80
THD<20%
Various Specifications
Part No.SES-W50SES-W75SES-W100SES-W150SES-W200SES-W300
Power50W75W100W150W200W300W
Size/mm560*196*99560*196*99610*245*99660*245*99712*300*99714*340*99
Luminous (LM)6750LM10100LM13500LM19950LM27000LM40500LM
Product Description

Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights, with 5 Years Warranty.  can be OEM and ODM for you.
LED Street Lights 50W, 75W, 100W, 150W, 200W, 300W, LED Street Light Various Specifications, 130&150LM/W, The Light Sensor Optional

1. 200W LED Street Lights Aluminum Alloy Housing, simple and stylish appearance;
2. 200W LED Street Lights Large heat dissipation area, good heat dissipation for long life performance;
3. Sensor Street Lights High temperature resistant tempered glass, surface baking process, strong corrosion resistance and durability;
4. 200W Street Lights Protection of the lamp shell is up to IP66, rugged all weather IP Construction;
5. Waterproo Street Lights Use super brighter 3030smd to obtain high light efficiency, 130&150 lumens per watt;

Model(Size A)(Size B)(Size C)(Size D)
SES-W50 L Type560mm196mm99mm60mm
SES-W75 L Type560mm196mm99mm60mm
SES-W100 L Type610mm245mm99mm60mm
SES-W150 L Type660mm245mm99mm60mm
SES-W200 L Type712mm300mm99mm60mm
SES-W300 L Type714mm340mm99mm60mm
Installation Instructions
Product packaging
ModelQty/ctnN.W/PCSCTN Size (mm)
SES-W50 L Type1pcs2.8kg595*225*160
SES-W75 L Type1pcs2.8kg595*225*160
SES-W100 L Type1pcs3.5kg645*275*160
SES-W150 L Type1pcs4.0kg695*275*160
SES-W200 L Type1pcs5.2kg745*330*160
SES-W300 L Type1pcs6.8kg750*370*160
Application
Outdoor 150lm/W Wireless Waterproof Motion Sensor All In One 200W LED Street Lights
Suitable for Parking Lights, Road Lighting, Ramp Lighting, Sidewalk Lighting, Campus Lighting, Highway lighting and other outdoor places.
