Model NO.
SE-4T30W-P
Quantity:
Product Parameter
Model NumberSE-4T30W-P
Beam Angle120°
Waterproof GradeIP66
Color Temperature
(CCT)
3000K/4000K/5000K/6000K
Power20W/30W/40W/50W
Lighting solutions serviceLighting and circuitry design;
DIALux evo layout; CAD layout
CertificationCE ROHs SAA ETL DLC
ApplicationParking Lot, Car Washing,
Cold Storage
Warranty(Year)5-YEAR
Luminous Efficacy(lm/w)130
Life time(Hour)50,000
Power Factor (PF)≥0.95
IK RateIK08
Flicker Freeyes
FunctionNormal / 0-10V Dimmable /
DALI Dimmable/ Emergency / Sensor
Input Voltage(V)AC 220-240V/100-277V
LED2835 SMD
Ambient Temp. ()-20~+50℃
Storage Temp. ()-40~+85℃
Key MaterialAluminum Housing +PC Cover
DriverLiFud, Passed TUV
CRI (Ra>)80 / 90
Various Specifications
Part No.SE-2T20W-PSE-4T20W-PSE-4T30W-PSE-4T40W-PSE-5T50W-P
Power20W20W30W40W50W
Size/mm600*71*55mm1200*71*55mm1200*71*55mm1200*71*55mm150071*55mm
LED Type315PCS315PCS384PCS396PCS477PCS
Luminous (LM)2600LM2600LM3900LM5200LM6500LM

Product Description

P Type IP66 LED Tri-Proof Lights 4T30W Waterproof Light Fixture Explosion Proof Light, can be different function like 0~10V Dimmable, DALI Dimmable, Emergency, Microwave Sensor, Flicker Free, IK08, 130LM/W efficiency, CRI 80Ra, with 5 Years Warranty. This is SE.Lighting own designed  can be OEM and ODM for you, Silver Color or Black Color, can Laser your LOGO onto the product.
Features of our IP66 LED Tri-Proof Lights :

1. LED Tri-Proof Lights Up to 50% energy saving compared to tradition lights.
2. LED Tri-Proof Lights With high Lumen 2835 Led Chips and Lifud Led Driver, 5 Years warranty.
3. LED Tri-Proof Lights High Impact IK08 Test.
4. LED Explosion Proof Light High Lumen output up to 130lm/w.
5. LED Tri-Proof Lights (P Type) ,Dust-proof and Corrosion-proof.
6. LED Tri-Proof Lights Extrusion design for the lamp body,higher watetproof performance, Water proof, IP66 grade.
7. LED Waterproof Light Fixture Two installation modes for selection; ceiling holder and suspension rope.


Emergency
Model NO.Emergency Time (hour)Emergency Brightness (Power)Battery Parameters
SE-2T20W-P36W  (30% Brightness)7.2V 3600mAH
SE-4T20W-P36W  (30% Brightness)7.2V 3600mAH
SE-4T30W-P39W  (30% Brightness)7.4V 4400mAH
SE-4T40W-P312W  (30% Brightness)12V 4000mAH
SE-5T50W-P315W  (30% Brightness)12V 5000mAH
Self-Inspection Function:
1. By Monthly: After charge in 48hours continuously, it will start to counting, 30days a cycle, and then turn on in the emergent mode and lighting on 30second for self Inspection.
2. By Yearly: Likewise, 12 months a cycle, it will turn on in the emergent mode and lighting on ≥30 minutes for self Inspection.




​​​​​

Light Distribution Graph
Model No.PowerFlux (Lux)*
1M2M3M4M
SE-2T20W-P20W877 lux219 lux97 lux55 lux
SE-4T20W-P20W928 lux232 lux103 lux58 lux
SE-4T30W-P30W1408 lux351 lux156 lux87 lux
SE-4T40W-P40W1859 lux464 lux206 lux116 lux
SE-5T50W-P50W2283 lux570 lux253 lux142 lux
Application
IP66 Waterproof LED Tri-Proof Lights Fixture can be widely used in Public Lighting and Commercial Lighting . Like Metro Station Lighting, Train Stations Lighting, Bus Stations Lighting, Airports Lighting, Corridor Lighting, Car Parks Lighting, Stairwells Lighting, Service Centre Lighting, Gallery Lighting, Horse Farm Lighting, Swimming Pool Lighting and etc.



Dimension
ModelSize A(mm)SizeB(mm)SizeC(mm)
SE-2T20W-P6007155
SE-4T20W-P12007155
SE-4T30W-P12007155
SE-4T40W-P12007155
SE-5T50W-P15007155
Product packaging

Model NoLengthQTY/CTNN.W./PCSG.W/CTNInner Box (mm)CTN Size (mm)
SE-2T20W-P0.6m9pcs0.61Kg6.69 Kg650*80*65670*260*220
SE-4T20W-P1.2m9pcs1.03Kg11.87Kg1250*80*651270*260*220
SE-4T30W-P1.2m9pcs1.08Kg12.32Kg1250*80*651270*260*220
SE-4T40W-P1.2m9pcs1.08Kg12.32Kg1250*80*651270*260*220
SE-5T50W-P1.5m9pcs1.36Kg15.55Kg1550*80*651570*260*220
Installation Instructions
